Richerlink ONU- RL801E EPON Interface Rate Upsteam: 1.25Gbps Downsteam: 1.25Gbps Interface standard IEEE802.3ah EPON standard Launch power Min: 0dBm Max: +4dBm Sensitivity -27dBm Input Power Overload -7dBm Service Interface EPON Interface 1 EPON Port Data Interface 1 GE Environmental conditions Storage temperature -10 to 70°C, rel. humidity 10–90% (non-condensing) Operation temperature 0 to 45°C, rel. humidity 10–90% (non-condensing) Power Supply and Consumption Power Adaptor Input: 100 to 240 V AC, 50/60 Hz; Output: 12 V, 0.5A Consumption =4W Physical specifications Dimensions 108mm×85mm×26mm(L×W×H) Weight 0.20KG
